PSI - Gen 4 LS Standalone Harness (58X) DBW Uscar 6L80E

PSI - Gen 4 LS Standalone Harness (58X) DBC Uscar 6L80E Transmission

Product Details

• DBW (electronic throttle body)
• LS gen 4 (58X reluctor)
• 6L80E transmission
• Uscar fuel injector
• Includes: instruction, wire harness w/ sliding grommet seal

Additional Items Required

• E38 ECM

The harness includes connections for

• Fuse and relay box
• Fuel pump control (relay included)
• Fan controls (relays and fuse available separately – use PSI-FAN)
• Check engine light
• Speedometer
• Tachometer
• OBD2 diagnostic port

• Accelerator pedal Corvette (connector)
• Throttle body DBW (connector)
• MAF sensor 5 wire, card style (sensor)
• MAP sensor (delphi connector, connector)
• Engine coolant temperature sensor, 2 wire (connector)
• Alternator (2 pin, connector)
• (2) Black Trapezoid upstream oxygen sensors (connector)

• Crankshaft position sensor
• Camshaft position sensor
• Fuel injectors (EV6 / USCAR / connector)

• Coil packs (connector) requires 2 coil harnesses, NOT included, such as harness
• Automatic transmission control for 6L80E / 6L90E
• Knock sensors (connector)
• Oil pressure sensor LS3 (sensor, connector)


Connections from the harness you will need to hook up

• Fuel pump
• Switched ignition power
• Malfunction indicator (CEL/MIL)
• Speedometer
• Tachometer
• Fan 1 relay control (low/single fan)
• Fan 2 relay control (high/second fan)

Additional Info

• For retrofitting Gen 4 LS engines into non-emissions controlled vehicles
• Requires switched power, constant power, and ground connections
• Includes 4–5 feet of wire length from rear of cylinder head to PCM mounting location
• Sliding grommet for sealed firewall pass-through
• Built with GM Delphi connectors and TXL high-temp automotive-grade wire
• 100% quality inspected before shipping
• PCM must have VATs removed (available through PSI)
• DOD/AFM not supported

Photos of products are sample images. Actual product may vary.
