BTR Trinity Gen V with Port Injection

Prix
$1,029.99
UGS#: BTR-TRA-GENV-INJ-BLK-ML
Il ne reste que 1 en stock !

Description du produit

TRInity Series Intake Manifold Package for LT Engines!

– Version 2


The latest offering from BTR in high quality cast aluminum intake manifolds! TheTRInity is short runner, 3-piece design that allows for the ultimate in application flexibility. It is similar in concept to billet Intakes costing thousands more. Accepts DBW or cabled throttle bodies*, and short-runner versions will fit in the tight confines of the C7, C6, C5 Corvette as well as the popular F-body platforms. The design incorporates 2 runners and an interchangeable plenum. The seal is generated by 8 entrapped o-rings at the runner/plenum interface, and is clamped by 20 M6 Stainless steel socket head cap screws. The port seals are achieved SAE o-rings seated in a dovetailed oiring groove for maximum sealing in boosted applications. Both the port mouth radius and the port match is CNC machined for optimum balanced flow. The manifold comes semi-assembled and includes all the hardware required to bolt it on. Runners and plenums can be purchased separately.
Warning Prop 65 >>

BTR Trinity Gen V with Port Injection

UGS#: BTR-TRA-GENV-INJ-BLK-ML
Il ne reste que 1 en stock !
Prix
$1,029.99
free shipping over $100

& 90 day returns Policy

Description du produit

TRInity Series Intake Manifold Package for LT Engines!

– Version 2


The latest offering from BTR in high quality cast aluminum intake manifolds! TheTRInity is short runner, 3-piece design that allows for the ultimate in application flexibility. It is similar in concept to billet Intakes costing thousands more. Accepts DBW or cabled throttle bodies*, and short-runner versions will fit in the tight confines of the C7, C6, C5 Corvette as well as the popular F-body platforms. The design incorporates 2 runners and an interchangeable plenum. The seal is generated by 8 entrapped o-rings at the runner/plenum interface, and is clamped by 20 M6 Stainless steel socket head cap screws. The port seals are achieved SAE o-rings seated in a dovetailed oiring groove for maximum sealing in boosted applications. Both the port mouth radius and the port match is CNC machined for optimum balanced flow. The manifold comes semi-assembled and includes all the hardware required to bolt it on. Runners and plenums can be purchased separately.
Warning Prop 65 >>

Product Specifications

Manufacturer Part Number UPC Weight
Brian Tooley Racing BTR-TRA-GENV-INJ-BLK-ML 35.29 lb
