Cylinder head must have 3/8 threaded hole for alternator (same as water pump bolt thread)

Does NOT include pulleys

BBC Alternator & Power Steering Bracket Kit

• Compatible with big block Chevy engines
• Compatible with long water pump and 36P1435 style power steering pump
• Made in Wichita, Kansas from aerospace grade, USA produced, billet aluminum
• This kit will work with V-belt (1, 2, or 3 rib pulleys)
• Includes: alternator and P.S. pump bracket, instructions, and mounting hardware

Suggested Power Steering Pump Part # 36P1435 (see photo) Bracket is only compatible with the shown pump style Uses " V-belt for power steering pump (with factory pulley diameters) Uses " V-belt for alternator (with factory pulley diameters) This kit must be used with Long Water Pump and Pulleys. Recommended water pump part # DWP-442 Suggested Crank Pulley Part #14023148 Suggested Water Pump Pulley Part #14023155 Suggested Power Steering Pulley Part #14023173 Suggested AC Delco alternator part # 335-1093 Compatible with Chevy alternators with 6.56 inch, center to center bolt holes (12si style alternators)
